Engineered Fire Hose Cabinets
Precision-manufactured fire hose cabinets designed for safe equipment storage, instantaneous emergency access, and robust physical protection in commercial offices, industrial plants, and high-rise towers.
Key Features of Dorprime Fire Hose Cabinets
Manufactured under strict ISO-certified engineering protocols to ensure immediate fire responsiveness, long-term durability, and structural elegance.
Robust Construction
Manufactured using high-grade Mild Steel, Galvanized Iron (GI), or Stainless Steel (SS 304/316), providing immense structural rigidity, impact resistance, and extended service life.
Corrosion Resistant Finish
Finished with pure polyester powder coating in high-visibility Fire Red (RAL 3000) or brushed stainless steel, ensuring resistance against moisture, humidity, and aggressive ambient chemicals.
Easy Accessibility
Designed with user-friendly 180° swing doors and crystal-clear vision panels, allowing building occupants and fire responders quick, unobstructed access to hoses and nozzles during emergencies.
Multiple Mounting Options
Engineered in wall-mounted (surface), semi-recessed, and fully recessed configurations to seamlessly match architectural lobby layouts, stairwells, and industrial plant walls.
Precision Fit for Every Wall Cavity
Every cabinet is fabricated using CNC turret punching and automated press-brake bending to ensure seamless 90° corners, airtight perimeter rubber beading, and flawless latch engagement.
- Double fold safety edges preventing cuts during rapid deployment
- Concealed or piano-type hinges tested for 50,000 opening cycles
- Knockout conduit openings for electrical alarm sensor integration
Types of Fire Hose Cabinets (FHC)
Available in single-door swinging hose reel designs and heavy-duty double-door dual compartment enclosures.
Single Door Fire Hose Cabinet
Compact heavy-gauge steel cabinet engineered to accommodate standard swinging fire hose reels, branch pipes, and nozzles. Ideal for corridor walls, staircases, and residential towers.
Double Door Fire Hose Cabinet
Heavy-duty dual-compartment enclosure engineered to house a swinging hose reel in the upper section and fire extinguishers / landing valves in the lower section for complete firefighting readiness.
Over 40,000+ FHC Units Installed Across India
Trusted by top tier IT parks, pharma plants, real-estate conglomerates, and hospital healthcare facilities.
Specifications of Fire Hose Cabinets
Engineered to meet and exceed national fire safety norms. Review complete dimensional and material parameters below.
| Specification Parameter | Technical Details & Options |
|---|---|
| Material Options | Mild Steel (MS) / Galvanized Iron (GI) / Stainless Steel (SS 304 & 316) |
| Body Sheet Thickness | 0.8mm / 1.0mm / 1.2mm |
| Shutter Sheet Thickness | 0.8mm / 1.0mm / 1.2mm |
| Core / Shutter Construction | Single Sheet Reinforced / Double Skin Hollow Metal |
| Frame Section | 90mm X 45mm precision roll-formed profile |
| Protective Surface Finish | Pure Polyester Powder Coated (RAL 3000 Signal Red) / SS Hairline |
| Inspection Glass Panel | 4mm Clear Float Glass / 5mm Toughened Safety Glass |
| Mounting Style | Surface Wall Mounted / Semi-Recessed / Recessed into masonry |
| Locking & Latching | Cam key lock / Break glass emergency key box / Push knob |
| Signage & Labeling | Screen printed 'FIRE HOSE' in English & Hindi with reflective graphics |
| Compliance Standards | Conforming to IS 3844, NBC 2016 Part 4 & NFPA 14 standards |
Advantages of Dorprime Fire Hose Cabinets
Fire hose cabinets are designed to ensure safe storage, quick accessibility, and protection of fire-fighting equipment. They play a crucial role in improving emergency response efficiency and maintaining organized fire safety systems.
Quick Access During Emergencies
Engineered for instantaneous opening, enabling first responders and security personnel to deploy hoses and valves within seconds without jamming or delay.
Protects Critical Fire Equipment
Safely encloses high-pressure hoses, swinging reels, branch nozzles, and landing valves from dust, vandalism, chemical vapours, and physical impacts.
Enhances Fire Safety Compliance
Fully complies with National Building Code (NBC 2016 Part 4) and IS 3844 requirements for commercial, industrial, and high-rise developments across India.
Durable & Strong Build
Manufactured from prime tested steel sheets with welded seam construction, providing uncompromising durability and rigidity under tough conditions.
Organized Equipment Storage
Keeps hoses coiled properly, nozzles docked, and landing valves clear, preventing tangles and ensuring fast inspection during statutory audits.
Low Maintenance & Long Life
High-grade 7-tank pre-treatment and electrostatic powder coating prevent rust formation, minimizing lifetime maintenance costs.
Why Choose Dorprime for Fire Hose Cabinets?
As a direct plant manufacturer, we fabricate custom dimensional enclosures matching exact wall niches, architectural finishes, and statutory project tenders with prompt pan-India dispatch.
Talk to Our Fire Safety Experts
Get technical consultation, shop drawings, custom sizing, and direct factory pricing for your project.
